Improving the Energy Performance of a Convention Center Building
Main Article Content
Abstract
Energy-efficient design is becoming very important not only for the depletion rate of energy resources but also for the reduction of the carbon dioxide gas emission. To be able to obtain the highest efficiency with the lowest energy consumption several measures can be taken such as the improvements of envelope’s thermal performance, ,and the use of active and passive systems.
In this study, improvement suggestions for the application of an energy-efficient conference center located in Soma, Manisa (in Turkey), a province with a semi-humid climate, have been examined. Different strategies have been presented by using passive and active solutions to meet the credentials of the “Net Zero Energy Building” or “Approximate Zero Energy Building.” First, the three-dimensional energy model of the building was created through the eQUEST program by using the current plan and other building specifics. Buildings cause significant energy consumption during their life-span and consequently, environmental effects are integral. For the second stage of the study, the energy improvement method of the conference was achieved by proposing different layers in the building elements, whilst PV panels being mentioned as an active solution. In line with the strategies created, changes in energy performance were evaluated through the eQUEST program. According to the energy analysis results data of the “Current Situation” and “Improvement Scenarios” on the annual use of the Conference Center Building, total energy efficiency increases by 26%. This performance is achieved with an efficiency of 19% in electricity consumption and 38% in gas consumption, and an increase in energy performance is observed with a decrease in total energy consumption. In addition, it has been observed that a total of 223.1 MWh can be achieved annually with 525 modules installed on the green roof using “PVsyst” program for photovoltaic panels, which are proposed to be integrated as renewable energy sources.
Article Details
![Creative Commons License](http://i.creativecommons.org/l/by-nc-nd/4.0/88x31.png)
This work is licensed under a Creative Commons Attribution-NonCommercial-NoDerivatives 4.0 International License.
References
Aksakal, H. (2011). Analysis of the impact of building automation systems on energy efficiency. Thesis (M.Sc.), Istanbul Technical University, Institute of Energy, Istanbul.
Aksamija, A. (2016). Regenerative design and adaptive reuse of existing commercial buildings for net-zero energy use. Sustainable Cities and Society, 27, 185–195.
Aksungur, K. M., Kurban, M., & Filik, Ü. B. (2013). Analysis and Evaluation of Solar Radiation Data in Different Regions of Turkey. Energy Efficiency and Quality Symposium.
Berge, B. (2001). The Ecology of Building Materials. United Kingdom: Architectural Press.
Capeluto, I.G., A. Yezioro & E. Shaviv (2003). Climatic Aspects in Urban Design: A Case Study, Elsevier, Building and Environment, Faculty of Architecture and Town Planning. Technion-Israel Institute of Technology, 38 (6), 827.
Ceylan, N. (2012). Environmental Assessment of Production and Construction Phases of Heat Insulation Applications Widely Preferred in Residential Exterior Wall Systems in Turkey. Thesis (M.Sc.), Istanbul Technical University, Institute of Science and Technology, Istanbul.
Cooperman, A., Dieckmann, J. & Brodrick, J. (2011). Commercial envelopes. ASHRAE Journal, 53 (2011), 134-136.
Demir, Ş. (2012). Current Point and Future Projections in Solar Energy. Retrieved December 29, 2019, from http://www.gensed.org/pdf/sunum.pdf
Dikmen, Ç. B. & Savcı, S. (2015). Sürdürülebilir Yapı Tasarımı Kapsamında Çevre Dostu Yeşil Çatı Uygulamalarının İrdelenmesi, 2. Uluslararası Sürdürülebilir Yapılar Sempozyumu, 214-220, May 28-30, Ankara.
Dilek Cam (2019). PVC Construction Contracting Industry and Trade LTD.Co., Retrieved December 31, 2019 from http://www.dilekcam.com.tr/ws/performans-tablolari/
Erkmen, F. İ. (2005). Sıcak İklim Bölgelerinde Yapıların Soğutma Yüklerinin Karşılaştırılması (Antalya, Diyarbakır Örneği). Thesis (M.Sc.), Yıldız Technical University, Institute of Science and Technology, Istanbul.
Erkul, E. (2012). Yeşil Çatı Sistemlerinin Yapım Açısından İrdelenmesi. Thesis (M.Sc.), Dokuz Eylül University, Institute of Science and Technology, Izmir.
Gazioğlu, A., Akşit, Ş. F. & Manioğlu, G. (2013). Enerji Etkin Bina Tasarımında Isıtma Enerjisi Tüketimini Azaltmaya Yönelik Bir İyileştirme Çalışması. Tesisat Mühendisliği Dergisi, 136, 41-52.
GeoGreen Green Roof System. (2020). Green Roof System. Retrieved January 1, 2020 from https://www.istanbulteknik.com/Dosyalar/pdf/geogreen_tr.pdf
Google. (2020). Google Earth. Retrieved June 13, 2020 from .
Güneş, O. (2019). Installation of Photovoltaic Systems on the Roof of a Housing Building. Thesis (M.Sc.), Istanbul Technical University, Institute of Energy, Istanbul.
Hermelink, et al. (2013). Towards Nearly Zero-energy Buildings: Definition of Common Principles Under the EPBD. Ecofys, Koeln.
İzocam. (2002). Isı Yalıtımı-Teknik Yalıtım-Ses Yalıtımı-Yangın Yalıtımı. İzocam Yayınları, 77-79.
Karadağ, A. (2006). Changing Environment, City and Identity in Soma after Lignite Extraction and Thermal Power Plant. Aegean Geographical Journal, 15/31-50, Izmir.
Liu, K. & Baskaran, B. (2003). Thermal Performance of Green Roofs through Field Evaluation. Greening Rooftops for Sustainable Communities, Chicago.
Municipality of Soma. (2019). Municipality of Soma. Retrieved December 30, 2019 from https://www.soma.bel.tr/sayfalar/hakkinda/69
Özkılıç Keleş, C. (2008). A Study About Photovoltaic Systems in Point of Energy Efficiency on the Buildings in Turkey. Thesis (M.Sc.), Istanbul Technical University, Institute of Science and Technology, Istanbul.
Özmen, E. (2018). Solar Cities as a Model in Usage of Renewable Energy Sources: Manisa Sample. Thesis (M.Sc.), Istanbul Technical University, Institute of Science and Technology, Istanbul.
Özüpak, Ö. Ş. (2008). The Assessment of the Energy Performance Criteria for the Commercial Buildings. Thesis (M.Sc.), Istanbul Technical University, Institute of Science and Technology, Istanbul.
Parasonis, J., Keizikas, A. & Kalibatiene, D. (2012). The Relationship Between the Shape of a Building and Its Energy Performance. Architectural Engineering and Design Management, 8(4), 246-256.
Republic of Turkey Ministry of Energy and Natural Resources (2016). Project Development Process with Integrated Building Design Approach Implementation Guide. Ankara. Retrieved January 1, 2020 from https://webdosya.csb.gov.tr/db/meslekihizmetler/ustmenu/ust menu838.pdf
Şahinoğlu, S. (2012). Heating/Cooling Energy and Visual Comfort Perfromance Evaluation of Windows with Various Shading Devices. Thesis (M.Sc.), Istanbul Technical University, Institute of Science and Technology, Istanbul.
Sanat Zemin ve Yapı A.Ş. (2020). Sanat Zemin ve Yapı A.Ş. Retrieved January 4, 2020 from https://www.sanatzemin.com/neden-epoksi-zemin/
Sezer Cam & Alüminyum. (2020). Sezer Cam & Alüminyum. Retrieved January 1, 2020 from http://www.sezercam.com/ISICAMARGON
Sezer, F. (2005). Farklı cam türlerinin performans kriterlerinin incelenmesi. Uludağ University Mühendislik – Mimarlık Fakültesi Dergisi, 10(1).
Sözer, H. (2010). Improving energy efficiency through the design of the building envelope. Building and Environment, 45, 2581-2593.
Technical Assistance Project for Improving Energy Efficiency in Buildings. (2016). Handbook of Energy Systems in Buildings and Measurement Methods. Retrieved January 1, 2020 from https://webdosya.csb.gov.tr/db/meslekihizmetler/ustmenu/ustmenu841.pdf
Tera Solar. (2020). Tera Solar. Retrieved June 21, 2020 from http://www.tera-solar.com/urun/300w-polikristal-fotovoltaik-panel.
The U.S. Department of Energy by the National Institute of Building Sciences. (2015). A Common Definition for Zero Energy Buildings. Retrieved January 1, 2020 from https://www.energy.gov/ sites/prod/files/2015/09/f26/A%20Common%20Definition%20for%20Ze ro%20Energy %20Buildings.pdf
TS EN 15232. (2008). Energy Performance of Buildings – Estimated Results of Building Automation, Control and Building Management. TS EN 15232.
Turkish Solar Power Atlas – GEPA. (2019). Güneş Enerjisi Potansiyeli Atlası. Retrieved December 29, 2019 from http://www.yegm.gov.tr/ MyCalculator/pages/45.aspx
Turkish Standard0 (2008). TS 825. Thermal Insulation Requirements for Buildings. May 2008.
Turkish Standard. (2013) TS 825. Thermal Insulation Requirements for Buildings, December 2013.
Tzempelikos et al. (2010). Indoor thermal environmental conditions near glazed facades with shading devices – Part II: Thermal comfort simulation and impact of glazing and shading properties. Building and Environment, 45, 2517-2525.
U.S. Department of Energy. (2009). Recovery Act Announcement: Obama Administration Launches New Energy Efficiency Efforts. EERE News.
Utkucu, D. & Sözer, H. (2019). Investigation of a Traditional House Based on its Energy Conservation. Journal of Building Energy Environment: BEE, 3, ISSN: 26.
Weiler, S. & Katrin, S.B. (2009). Green Roof Systems – A Guide to the Planning, Design and Construction of Landscape Over Structure. Hoboken, New Jersey: John Wiley & Sons, Inc.
Yıldırım, E. (2018). Kil Esaslı Yapı Malzemelerinin Çatı ve Cephelerde Geçmişten Günümüze Sürdürülebilir Kullanımı, 9. Ulusal Çatı & Cephe Konferansı, Istanbul Kültür University, Bakırköy, Istanbul.
Yüksel, Ç. Y. (2019). Energy Efficiency for Hot-Humid Climate Based on Openings and Roof Type, Adana Case. Thesis (M.Sc.), Çukurova University, Institude of Natural and Applied Sciences, Adana.
Zoroğlu, F., Atmaca, A., B., Zorer, Gedik, G. (2018). Çevresel Sürdürülebilirlik Kapsamında Konutta Isıl Konforun Sağlanması ve Enerji Tüketiminin Azaltılması, İstanbul 1. Konut Kurultayı.
